Basic Info.
Model NO.
DG11000E3
Type
Self-Starting Diesel Generator
Installation Method
Portable
Stroke
Four Stroke
Cooling Method
Wind Cooling
Output Type
AC Three Phase
Speed
Speed
Conditions of Use
Land Use
Usage
Common Units
Landuse Type of Unit
Ordinary
Excitation Mode
AC Rotating Exciter
Engine Model
Hr198fa
Engine Power
15HP
Generator Power
8kw
Transport Package
Carton
Specification
CE, GS, ROHS, ISO9001-2008
Trademark
Hi-earns or OEM
Origin
Jiangsu, China
HS Code
85021100
Production Capacity
50PCS/Day
Product Description
* Generator model: Air-Cooled Open Frame Type Diesel Generator Set (DG11000E3)
* With 15HP HR198FA diesel engine, ensure a 7.5KW rated output and 8KW max. Output. Portable model can be easy move, stable power output adopted by several family!
* All spare parts pass Strict and Accurate raw material detection(IQC); All finished products detection Match ISO standard;
* Warranty: Running 500 hours or one year. Can support free spare parts for repairing during warranty time also low than market price spare parts out of warranty time!
* Modern Production Workshop, strict producing process, ensure a Fast and High-quality products output
* 100% copper good brand alternator, every spare parts suppliers are choosed extremely strict, to control the quality well.
As a professional generator manufacture, I think we must have one type even more can match what you need!
Just send us your inquiry, we will highly appreciate it!
| generator | model | DG11000E3 |
| Frequency(HZ) | 50 | |
| Max. Output (kw) | 8.0 | |
| Rated output (kw) | 7.5 | |
| Rated. AC voltage(V) | 220/380,230/400 | |
| Power factor(cos& phi) | cos& phi=0.8 | |
| DC output(V) | 12V/8.3A | |
| Phase | Three phase | |
| Alternator type | Self-excited, 2-pole, three phase alternator | |
| Starting system | Electric | |
| Operatong noise lecel(at 7m) | 80-85 | |
| Fuel tank capacity(L) | 12.5 | |
| Continues work(hr) | 5 | |
| engine | Model | HR198FA |
| Engine type | Single-cylinder, vertical, 4-stroke air-cooled diesel engine | |
| Bore*stroke(mm) | 98*84 | |
| Fuel | 0# or -10#light diesel oil | |
| Lubricatiom oil volume (l) | 1.65 | |
| Combustion system | Direct lnjection | |
| standard features | Voltmeter | yes |
| AC Output Socket | 2 | |
| AC circuit breaker | yes | |
| Oil warning light | yes | |
| Oil alert | yes | |
| optional features | DC circuit breaker | Optional |
| Calculagraph | Optional | |
| Big Wheel | Optional | |
| Three phase volatge | Optional | |
| Current meter | Optional | |
| ATS | Optional | |
| Remote control | Optional | |
| Welding | Optional | |
| dimensions | Dimension(L*W*H)(mm) | 760*530*680 |
| Dry weight(kg) | 147 | |
| 20FT | 99 |
